Home  >  Refrigeration  >  Controls/Accessories  >  Motors-Controls  > 25317701S LARKIN SINGLE

25317701S LARKIN SINGLE SPEED EC MOTOR 1/15HP 230V 1525 RPM .48A CWSE

Item #: 106181
Manufacturer Item: 25317701
Manufacturer: HEATCRAFT REFRIGERATION PROD
137583

IP66 Dust Tight with All Angle Moisture Protection

Double Pedestal

Thermally Protected

Robust Ball Bearing System

Standard 3-Hole Style/Hussmann 4-Hole on Back of Motor

Thermal Protection Electronically Protected

Motors-Controls

Power Rating
1/30 HP
Voltage Rating
115 to 230 Volt AC 1-Phase
Speed Rating
1550 to 1725 RPM
Frequency Rating
60 Hertz
Application
HVAC and Refrigeration System
Enclosure Type
TEAO
Motor FLA
0.22 to 0.75 Amp
Number of Speeds
Variable
Mounting
Universal
Approval
UL (Canada and US)
Insulation Class
A
Service Factor
1
Frame Material
Aluminum
Efficiency
65 Percent
