Home  >  Plumbing  >  Pipe & Fittings  >  Compression & Flare  > 18-062LF 1/8 COMPRESSION UNION

18-062LF 1/8 COMPRESSION UNION

Item #: 11684
Manufacturer: JONES STEPHENS CORP
1/8" x 1/8", Compression x Compression, 400 PSI, Lead-Free, Brass, Straight, Union
11684

Not Intended for Steel Tubing

Designed for Use with Potable and Non-Potable Water, Instrumentation, Hydraulic and Pneumatic Systems

Little to No Tube Preparation Required. Connection Does Not Require Flaring, Soldering, or Other Types of Tube Preparation

Plastic and Pex Tubing Installations Require Sleeves and/or Inserts

Lead-Free

Compression & Flare

Material
Brass
End Connection
Compression x Compression
Type
Straight
Application
Residential, Commercial
Temperature Rating
-65 to 250 Deg F
Pressure Rating
400 PSI
Thickness
0.03 Inch
