Home  >  Plumbing  >  Valves  >  Safety  > 0065302 LF719QT WATTS 3/4

0065302 LF719QT WATTS 3/4 BACKFLOW PREVENTER LEAD FREE DOUBLE CHECK

Item #: 124420
Manufacturer: TCG - WATTS
3/4" x 3/4", FPT x FPT, 175 PSI, Lead-Free, Bronze, T-Handle, In-Line, Double Check Valve, Backflow Preventer
124420

Separate Access, Top Entry Check Valve Design

Reversible Seat Disc Rubber, Extends Check Valve Life

Chloramine Resistant Elastomers

Replaceable Seats and Seat Discs

Compact Design

Top Mounted Screwdriver Slotted Ball Valve Test Cocks

Low Pressure Drop

No Special Tools Required for Servicing

Plastic on Plastic Check Guiding Reduces Potential Binding due to Mineral Deposit

Lead-Free

Safety

Type
Double Check Valve Assembly, Shut-Off Valve, In-Line
Applicable Standard
UL (Canada and US), CSA (Canada and US), UPC, ASSE 1015, AWW
Body Material
Bronze
End Connection
Female Threaded x Female Threaded
Inclusions/Features
Reversible Seat Disc Rubber, Top Mounted Screwdriver Slotted
Application
Non-Health Hazard and Contaminants Found at the Service Line
Disc/Poppet Material
Silicone Rubber
End to End Distance
15-7/16 Inch
Pressure Rating
175 PSI
Seat Material
Engineered Plastic
Temperature Rating
33 to 180 Deg F
Valve Configuration
1/4 Turn, T-Handle
Flow Rate
7.5 Foot per Second
