Home  >  HVAC Service Parts  >  Motors  >  Actuator Motors  > GDE161.1P SIEMENS OPEN AIR

GDE161.1P SIEMENS OPEN AIR ELECTRONIC DAMPER ACTUATOR

Item #: 161905
Manufacturer: MISCELLANEOUS VENDOR
24 VAC 50/60 Hz, 44 Lb-Inch, Durable Plastic, Enhanced, Direct Coupled, Non-Spring Return, Electronic Damper Actuator
161905

Selectable Modulating Control Signal

Integral 1/2 Inch Conduit Connection

Manual Override

Low Energy Consumption

Quiet Operation

Independently Adjustable Dual Auxiliary Switches Available

Actuator motors

Type
Enhanced, Direct Coupled, Non-Spring Return
Angle of Rotation
90 Degree (Nominal), 95 Degree (Maximum)
Application
2-Position/Floating and Modulating Control of Building HVAC
Approval
UL (Canada and US), CE, EN60730-1, EN60730-2-14
Body Material
Durable Plastic
Enclosure
NEMA 2, IP54
Frequency Rating
50/60 Hertz
Maximum AC Voltage
24 Volt AC
Maximum DC Voltage
2 to 10 Volt DC
Minimum DC Voltage
0 to 10 Volt DC
Operating Temperature
-25 to 130 Deg F
Shaft Diameter
5/8 Inch
Torque
44 Inch-Pound
