Home  >  Plumbing  >  Pumps  >  Effluent  > FL31A LIBERTY .3HP EFFLUENT

FL31A LIBERTY .3HP EFFLUENT PUMP

Item #: 14136
Manufacturer Item: FL31A
Manufacturer: TCG - LIBERTY PUMPS
1-1/2" Discharge, FPT, 58 GPM, 1/3 HP, 1725 RPM, 115 VAC, 10' Cord, Automatic, Effluent Pump
14136

Vortex Impeller, Made of High Temperature Engineering Polymer, Permits Passage of Solids without Clogging

Cast Iron Construction with All Stainless and Brass Fasteners

Effluent

Applicable Standard
CSA (Canada and US), SSPMA
Discharge Head
19.8 Foot
End Connection
Female Threaded
Float Type
Wide Angle
Flow Rate
58 GPM at 5 Foot
Housing Material
Class 25 Cast Iron
Impeller Design
Vortex
Impeller Material
Polymer
Inclusions/Features
Impeller, Fastener, Permanently Lubricated Ball Bearing, Uni
Input Supply Rating
115 Volt, 10.5 Amp, 1-Phase
Motor Type
Oil Filled, Hermetically Sealed, Thermal Overload Protection
Power Cord Length
10 Foot
Power Rating
1/3 HP
Shaft Material
416 Stainless Steel
Shaft Seal Details
Carbon/Ceramic, Unitized
Speed Rating
1725 RPM
Temperature Rating
140 Deg F
Type
Submersible, Automatic
Warranty
3 Year
Application
Step System, LPP System, Mound System, Liquid Waste Transfer
